| Size (NB) | L +- (3.0) | OD +- (1.0) | RF Ø +- (2.0) | T +- (1.0) | PCD +- (1.6) | No. of Hole | Hole Ø |
|---|---|---|---|---|---|---|---|
|
25 |
257 |
107.9 |
50.8 |
14.3 |
79.4 |
4 |
16 |
|
40 |
257 |
127 |
73 |
17.5 |
98.4 |
4 |
16 |
|
50 |
257 |
152.4 |
92.1 |
19 |
120.6 |
4 |
19 |
|
80 |
257 |
190.5 |
127 |
23.8 |
152.4 |
4 |
19 |
| Sr. No | Description | Qty. | Material |
|---|---|---|---|
|
1 |
Body |
2 |
WCB, DI, Casting, CF8, CF8M + PFA, FEP, PVDF, PP, HDPE Lined Min. 3mm Lining Thk. |
|
2 |
Ball / Stem |
1 |
CF8 / CF8M + PFA, FEP, PVDF, PP, HDPE Lined Min. 3.5 mm Lining Thk (Cup Type) |
|
3 |
Valve Seat |
1 |
PTFE |
|
4 |
Gland Packing |
1 |
PTFE 'V' Ring |
|
5 |
Top Cover |
1 |
ASTM A 216 Gr. WEB / CF8 / CF8M |
|
6 |
Adapter |
1 |
ASTM A 216 Gr. WCB / CF8 / CF8M |
|
7 |
Gland |
1 |
ASTM A 216 Gr. WEB / CF8 / CF8M |
|
8 |
Lever Rod |
1 |
MS / SS / 304 |
|
9 |
Flange |
1 |
IS 2062 / SS 304 / SS 316 |
|
10 |
Drain Bush |
1 |
PTFE (Drilling Size - 12.0) |
|
11 |
Glass Bottle |
1 |
Borosilicate (Size - 50ml, 100ml) |
|
12 |
Fasteners |
4 |
SS 304 |
| Design Standard | ManufacturingStandard |
|---|---|
|
Test Standard |
API 598 / ISO 9393 - 2 / BS EN 12266 - 1:2003 |
|
Flange Connection |
ASME B 16.5; 150#, R/F |
| Carbon Steel | ASTM A 216 Gr. WCB |
|---|---|
|
Stainless Steel |
ASTM A 351 CF 8 / ASTM A 351 CF 8M |
| Size | Body |
|---|---|
|
25 to 80 NB |
15 kg/cm(sqr.) Seat: 11 kg/cm(sqr.) |
| PFA | ASTM D 3307 |
|---|---|
|
FEP |
ASTM D 2116 |
|
PVDF |
ASTM D 3222 |
15 kv dc
Note : SS 316 / SS 316 L unlined sampling valve also provided.
